参数 | 数据 | 说明 |
---|---|---|
Thread D1 | M85x2.0 | Means metric thread and the digits are major diameter of thread and pitch.Trmeans 30o; trapezoid thread and the digits are major diameter of thread and pitch. |
D3 | 110 mm | |
D4 | 102 mm | |
Bn | 16 mm | |
s | 8.0 mm | |
T | 3.5 mm | |
D6 | 86.0 mm | |
Lockwasher | MB 17 | |
Assembly Weight | 0.451 Kg |
